Automatic flow packing machine price
Short Description:
Automatic flow packing machine price for packing different kinds of regular shape products with or without holding a tray with the function of conveying, feed, weigh, make bag and output finished bags fully automatic.
Automatic flow packing machine price
Automatic flow packing machine price main features:
1.Man-machine interface, convenient parameter setting:
2. Double frequency control (optional servo motor). Bag length is cut. Without air conditioning go. One step, saving time and film:
3.Self-diagnostic function. Failure display:
4.High sensitivity optical electric color mark tracking, digital input cut position which makes the cutting position more accurately;
5.Temperature independent PI D control, and better suited to a variety of packaging materials.
6.Targeting stop function, not Sticking knife or wasting film.
7. Power train simple, more reliable, easier maintenance.
8. All controlled by the software.
|
||||||||||||||||||||||||||||||
| Model | PA100 | PA250 |
| Packing speed | 35-220bags/min | 35-180bags/min |
| Bag size | L65-200W30-90H5-30MM | L65-200W35-90H5-30MM |
| Film width | 65-220mm | 90-220mm |
| Packing materials | OPP,CPP,PT,PE,KPT ,CPP,ALU-FOIL | |
| Dimension | L:4000 X W:850X H:1600MM | L:3800 X W:850X H:1300MM |
| Heat power | 2.4KW | 2.1KW |
| Motor power | 0.2+0.4KW | |
| Total power | 3KW | 2.7KW |
| Total weight | 550KG | 550KG |
